山东海拓机械集团有限公司
|
最大工作高度Max working height |
2120mm |
|
|
|
最大装载高度Max pin height |
1865 mm |
|
|
|
最大卸载高度Max Dumping height |
1405 mm |
|
|
|
最大倾卸距离Max Dumping distance |
505mm |
|
|
|
最大卸载角度Max Dumping Angle |
35° |
|
|
|
总高度Total height |
1350 mm |
|
|
|
离地间隙Ground clearance |
121 mm |
|
|
|
轴距Wheel base |
|
|
|
|
无铲斗总长度Overall length without bucket |
1495 mm |
|
|
|
总宽度Total width |
990 mm |
|
|
|
铲斗宽度Bucket width |
1080mm |
|
|
|
带铲斗总长度Total length with bucket |
2245 mm |
|
|
|
折叠踏班不带铲斗总长度overall length without the bucket after folding the pedal. |
1990 mm |
|
|
|
发动机Engine |
润通R420 |
百利通13.5HP |
科普192（独立油箱） |
|
额定功率Rated Power (KW) |
10.5Kw/3600rpm |
10Kw/3600rpm |
10Kw/3600rpm |
|
转速Rotating speed (rpm) |
3600 |
3600 |
3000 |
|
噪声Noise (Db) |
≤95 |
≤95 |
≤95 |
|
液压系统Hydraulic System |
|
|
|
|
压力Pressure (Mpa) |
0-17 |
0-17 |
0-17 |
|
属具流量Flow rate |
0-18L |
0-18L |
0-15L |
|
工作负载Operating Load |
180 Kg(含属具自重) |
180 Kg(含属具自重) |
180 Kg(含属具自重) |
|
铲斗容量Bucket Capacity |
0.13m³ |
0.13m³ |
0.13m³ |
|
最大提升力Max Lifting Force |
200 Kg |
200 Kg |
200 Kg |
|
行驶速度Travel Speed |
0-3Km/h |
0-3Km/h |
0-3Km/h |
|
工作重量Operating Weight |
630kg |
630kg |
630kg |
|
油Oil |
|
|
|
|
燃油箱Fuel tank |
6.5L |
6.5L |
8.5L |
|
发动机机油Engine oil |
1.7L |
1.7L |
1.7L |
|
液压油箱 |
30L |
30L |
30L |
